WX8 2*6mm SMD 6pF 20ppm 32.768KHz tuning fork crystal
Tuning fork crystal
KEY_FEATURES:
- 1.Small size Φ2 x 6mm
- 3.Wide frequency range: 30kHz~350kHz
- 3.High reliability and high frequency stability
- 4.Suited for automatic mounting and reflow soldering
- 5.Environmentally friendly products, RoHS certified
WX8.pdfSale
¥0.80~1.00
IN_STOCK
LADDER_PRICE
-
FREE_SHIPPINGFREE_SHIPPING_DES
-
SUPPORT_TIMESUPPORT_TIME_DES
-
SAFETYSAFETY_DES
-
HOT_OFFERSHOT_OFFERS_DES
Series
WX8
Package/Case
DIP2060
Frequency
32.768 KHz
CL
6 pF
Frequency Tolerance （25±3℃）Min
-20 ppm
Frequency Tolerance（25±3℃）Max
+20 ppm
Operating Temperature Min
-20 ℃
Operating Temperature Max
+70 ℃
L x W/Size
2.0*6.0 mm
Drive Level
0.1~1 μW
Shunt Capacitance(C0)
1.45 pF
Storage Temperature
-40~+85℃ ℃
Aging
±5.0 ppm/year
Lead Quantity
2 Pin
Encapsulation technology
Metal Welded
Package type
Bag
MPQ
3000 pcs
Mounting type
SMT
Pb Free
Yes
Application level
Consumer
Partlife Cycle Code
Active
Material
Quartz Crystal
Insulation Resistance
500 MΩ @ DC100V
MFG
WTL International Limited
Country of Origin
China
Turnover Temperature
25±5 ℃
Temperature coefficient
(-0.035±10%) x 10^-6/°C^2
