CRYSTAL OSCILLATOR, OCXO, TCXO stability comparison

  • Oct 09,2022
  • 1234 VIEWS

Different applications will require different levels of performance. In some cases a crystal oscillator alone may be satisfactory, whereas for other applications a temperature compensated oscillator may be needed. For the highest specification requirements an oven controlled oscillator may be needed.

COMPARISON OF XTAL OSCILLATOR, TCXO & OCXO TEMPERATURE STABILITY PERFORMANCE
TEMPERATURE RANGE CRYSTAL OSCILLATOR TCXO OCXO
0C to 70C ±10 ppm ±0.5 ppm ±0.003 ppm
-20°C to 70°C ± 25ppm ± 0.5ppm ± 0.02ppm
-40°C to 85°C ± 30ppm ± 1ppm ± 0.003ppm

For applications that need even higher levels of stability, options including rubidium standards or some off-air GPS standards may provide the required levels of accuracy.
