WT3 3.2*2.5mm SMD 28.8MHz 3.3V 0.5ppm TCXO

IN_STOCK
TCXO
KEY_FEATURES:
Sale
¥7.90
IN_STOCK
STOCK 3000
BRAND WTL
LADDER_PRICE
QUANTITYPRICE
3000+¥ 7.90
  • FREE_SHIPPING
    FREE_SHIPPING_DES
  • SUPPORT_TIME
    SUPPORT_TIME_DES
  • SAFETY
    SAFETY_DES
  • HOT_OFFERS
    HOT_OFFERS_DES
Series
VC3
Package/Case
SMD3225
Frequency
28.800000 MHz
Supply Voltage
3.3 V
Tolerance
5 %
Output Level
0.8 Vp-p
Current Consumption
2.0 mA
Duty Cycle
45/55 %
L x W/Size
3.2*2.5 mm
Height
0.9 mm
Initial stability △25℃
2 ppm
Operating Temperature Min
-30 ℃
Operating Temperature Max
+85 ℃
△F vs △T
±0.5 ppm
△F vs △V
±0.2 ppm
△F vs △CL
±0.2 ppm
Output Load
10 pF
Start up Time
2 ms
Phase Noise
115/135/148 dBc/Hz
Control Function
GND
Output Wave
Clipped Sine Wave
Aging
3 ppm/year
Storage Temperature
-55~+125 ℃
Lead Quantity
4 Pads
Encapsulation technology
Seam Sealing
Package type
Tape/Reel
MPQ
3000 pcs
Mounting type
SMT
Pb Free
Yes
Application level
Consumer
Partlife Cycle Code
Active
Material
Quartz Crystal
MFG
WTL International Limited
Country of Origin
China
