TX9 1.2*1.0mm SMD 32.000MHz 8pF 20PPM Quartz Crystal
Quartz crystal
KEY_FEATURES:
- Size 1.2 × 1.0, ultra miniature and lightweight SMD crystal
- with a low profile of 0.33mm
- Seam with vacuum Sealed for Ultra-small size
- High precision and high reliability
- Automatic mounting is possible
- Reflow is possible
- RoHS Compliant / Pb Free
TX9.pdfSale
¥6.00~7.20
IN_STOCK
LADDER_PRICE
-
FREE_SHIPPINGFREE_SHIPPING_DES
-
SUPPORT_TIMESUPPORT_TIME_DES
-
SAFETYSAFETY_DES
-
HOT_OFFERSHOT_OFFERS_DES
Series
TX9
Package/Case
SMD1210
Frequency
32.000000 MHz
CL
8 pF
Frequency Tolerance （25±3℃）
±20 ppm
Operating Temperature
-40+85 ℃
Frequency Stability vs.Temperature
±30 ppm
L x W/Size
1.2*1.0 mm
Height
0.33 mm
E.S.R
32 to 96 Ω
Shunt Capacitance(C0)
3.0 pF
Storage Temperature
-55~+125 ℃
Drive Level
50 max μW
Aging
±5.0 ppm/year
Lead Quantity
4 Pad
Encapsulation technology
Seam Sealing
MPQ
3000 pcs
Package type
Tape/Reel
Mounting type
SMT
Pb Free
Yes
Application level
Consumer
Partlife Cycle Code
Active
Material
Quartz Crystal
Country of Origin
China
MFG
WTL International Limited
Special Requirement
No Special
